SKU: 666561425944
Color Temperatures:

Color Temperatures

VBDFS-COB480W2-xxxx-24S Indoor LED Strip Lights with Input Voltage: 24V DC, Wattage: 6W/m(2W/ft), Brightness: 510Lm/m(155Lm/ft), It can be used for cove lighting, under cabinet lighting, backlighting, and much more. This Long Run LED Strip(Ribbon) Light Series comes in 5Meter (16.4ft) rolls and is 10mm wide. This LED Strip(Ribbon) Light can be powered without experiencing voltage drop for the whole 5Meter (16.4ft) roll.


  • Model No: VBDFS-COB480W2-xxxx-24S
  • Input Voltage: 24V DC
  • Wattage: 6W per meter (2 W/ft)
  • Brightness: 510 Lm/meter (155 Lm/ft)
  • Lumen/LED: 1Lm Per LED
  • Available Color Temperatures:
    2700K (Soft White)
    3000K (Warm White)
    3500K (Mid-Warm White)
    4000K (Natural White)
    5000K (Daylight)
  • Dimensions: 5,000mm x 10mm x 2.15mm (196.8in x 0.4in x 0.08in)
  • Roll Length: 5meter per roll (16.4ft)
  • LED Qty: 480 LEDs per meter
  • LED Type: COB
  • Rendering Index: CRI>95
  • Lifespan: >50,000 hours
  • PCB: 3oz PCB, Double-side, White color 10mm width
  • Waterproof rating:  IP20 [Indoor use only]
  • Dimmable: Yes
  • Beam angle: 120°
  • Operating temperature: -15℃ to +40℃
  • Cut Size: Every 2 inches
  • Certifications: UL/RoHS


Model No.
(For each Color Temperature)
SKU
VBDFS-COB480W2-2700-24S 666561425944
VBDFS-COB480W2-3000-24S 666561425951
VBDFS-COB480W2-3500-24S 666561425968
VBDFS-COB480W2-4000-24S 666561425975
VBDFS-COB480W2-5000-24S 666561425982
