Veroboard 2-inch downlight is an IC-rated recessed light fixture. The IC rating housing prevents the engine from overheating thereby, increasing its life cycle. Moreover, they are designed to connect to a 12V class 2 power supply. This light fixture is air-tight and does not require any additional housing for installation. It is simple to install in a 2 inch (50 mm) hole size with easy push spring clips. Furthermore, this fixture has a rendering index of 90+, making objects visible in high-quality colors when illuminated. The fixture is available in both round and square trims and comes with housing.
The LED-1-S6W-3KWH-12V is a 2-inch round mini LED recessed downlight. It operates at a voltage of 12V AC/DC and has a wattage of 6W, providing a brightness of 480 lumens. The color temperature is 3000K (warm white), and it has a high rendering index of CRI>90. The LED driver is IC rated, and the downlight is dimmable with LED/CEL dimmers, with a dimming range of 100-10%.
The LED type is an integrated COB with a beam angle of 40°. The fixture is made of die-cast aluminum housing and is available in white color. It is air-tight and has an IP rating of IP20 for use in damp locations. The downlight is suitable for recessed/flush mount installation in insulated ceilings and damp locations.
The outer dimensions of the downlight are Ø 57 mm (2.25 in) x 73.3 mm (2.89 in) depth, and the cut size is 50mm (2 in). The package includes an IC-rated downlight with an installation manual. It has a package dimension of 2.8 x 2.4 x 4 in (7.2 x 6.1 x 10.2 cm). It is certified by FCC/ETL/RoHS.
